Ridgid 600-I Pipe Threader
The Ridgid 600-I (44918) is a compact, 12.7 lb (5.8 kg) handheld power drive designed for threading
1/8′′1 / 8 double prime 1/8′′ to 1 and 1/4′′ pipe using 11-R die heads. It features a 1/2HP, 115V motor operating at 36 RPM, a forward/reverse switch, and a die-cast aluminum gear housing for portability in service and repair applications.
Key Specifications for Ridgid 600-I (Model 44918):
- Die Heads: Compatible with 11-R
- Motor: 115V, 12A,1/2 HP, 1270W (Universal, Single Phase)
- Operating Speed: 36 RPM (no load)
- Weight: 12.7 lbs (5.8 kg) – Power Drive only
- Dimensions: 20 in. L x 3.75 in. W x 7.50 in. H
- Controls: Forward/reverse slide switch; Two-step momentary contact on/off switch
- Construction: Die-cast aluminum gear housing, fiberglass-reinforced plastic body
- Included Components: Usually includes 600-I Power Drive, 602 Support Arm, and Carrying Case
The unit is designed for easy handling with an over-molded grip,, making it ideal for on-site repairs. It is important to note that this is different from the heavy-duty 700 model, which has a larger capacity.
